Description
| MODEL | G2DB-60VSD | |
| MOTOR POWER | KW | 45 |
| FAD/Discharge Pressure | CFM/BAR | 276/7 |
| 257/8 | ||
| 225/10 | ||
| 206/12 | ||
| Cooling Method | Air Cooled | |
| Drive Type | Direct | |
| Dimensions (mm) | Length | 1150 |
| Width | 950 | |
| Height | 1350 | |
| Net Weight | Kg | 630 |
| Noise | dB(A) | 62 2 |
| Outlet Diameter | G11/2″ |
G2DB-60VSDdoes not include Vessel, Air Dryer or Filters.
Warranty Information
Screw / Rotarty Compressors include a 5 Year Warranty on the air-end and motor, 2 year warranty on pressure and temperature sensors, PLC, fan, after-cooler and VSD drives.
This is subject to an up to Date Factory Manual Service Contract. First Services to be carried out in 3 months thereafter every 6 Months is required, by approved Detroit Service Providers. Please seePower Tool TradersWarranty for full Warranty details.
